How to Use AlgoWayWS-MT5 EA 2.20 for TradingView to MT5 Webhook Automation

AlgoWayWS-MT5 EA is the MetaTrader 5 execution bridge for AlgoWay. It connects the AlgoWay platform to your MT5 terminal and lets structured signals from TradingView alerts, Telegram signals, manual webhook tests, or other supported sources become real MT5 trading actions.

This page is the current user-facing guide for the AlgoWayWS-MT5 EA 2.20 workflow. The file name still contains v206 because it originated from an earlier documentation cycle, while the content now reflects the current EA build and current AlgoWay platform direction: TradingView to MT5 webhook automation through AlgoWay and the AlgoWayWS-MT5 Expert Advisor.

All EA settings in this guide are named exactly as users see them in the MetaTrader 5 Inputs tab. Internal MQL variable names are intentionally not used for EA settings.

The complete execution route is:

TradingView alert -> AlgoWay webhook -> AlgoWayWS-MT5 EA -> MetaTrader 5 broker account

This guide explains what the EA does, how webhook JSON fields are interpreted, how trade modes work, how SL/TP and trailing rules are applied, and how to troubleshoot the most common MT5 execution problems.

Last updated: 2026-10-13 • Author: AlgoWay

EA 2.20 Update Notes

EA 2.20 adds EA-managed multiple Take Profit with up to four TP levels. Each level can close a percentage of the original position or a fixed number of lots. TP distances can be specified in pips or as percentages. The feature is disabled by default and is configured in the MT5 EA Inputs.

EA 2.19 introduced built-in Telegram Trade Reports, EA-based fixed lot sizing, the STANDARD pip mode, and stronger broker confirmation for position management. Position closes, partial closes and SL/TP modifications are now treated as completed only after the relevant MT5 broker result is confirmed.

The new Override JSON order_contracts for new entries option lets the EA use a fixed lot size for BUY and SELL entries. When enabled, the configured Fixed EA lot size replaces the entry size received in order_contracts. Close/flat sizing continues to use the existing close-volume logic.

Telegram Trade Reports are independent from AlgoWay Telegram notifications configured in the dashboard. Dashboard notifications report incoming alerts received by AlgoWay, while EA Trade Reports report the actual position and pending-order activity occurring in MetaTrader 5.

The new STANDARD pip mode uses one pip as ten broker points for every symbol. Existing AUTO, TRADINGVIEW, PERCENT and POINTS modes remain available, so existing configurations do not need to change unless a different distance interpretation is required.

Start Here: Current Setup and Support Guides

This page explains the EA behavior and JSON logic. For installation and platform setup, use the dedicated guides below.

Why AlgoWayWS-MT5 EA Exists

TradingView is powerful for charting, Pine Script strategies and alerts, but TradingView does not directly execute trades inside your MetaTrader 5 broker terminal. MetaTrader 5 can execute trades through Expert Advisors, but it needs a reliable way to receive the signal from outside.

AlgoWayWS-MT5 EA closes this gap:

• TradingView creates the signal;
• AlgoWay receives the webhook alert and validates the message;
• AlgoWayWS-MT5 EA keeps the MT5 terminal connected to AlgoWay;
• MetaTrader 5 executes the order through your broker account.

Competitors describe the same market need as a TradingView-to-MT5 bridge, webhook-to-EA connector, or alert automation layer. AlgoWay focuses this workflow around a dashboard, structured JSON, WebSocket EA delivery, logs, and multi-source signal routing.

What the EA Does and What It Does Not Do

The AlgoWayWS-MT5 EA is an executor. It receives commands routed by AlgoWay and performs trade actions in MetaTrader 5.

The EA can help with:

• opening BUY or SELL positions;
• closing positions with flat commands;
• modifying SL/TP where supported by the message and current route;
• handling trade modes such as Reverse, Hedge, Opposite and Inverse;
• applying SL/TP, trailing, breakeven and profit lock rules;
• mapping TradingView tickers to exact MT5 broker symbols;
• respecting configured position size mode, session filters and limits;
• writing useful logs in MetaTrader 5.

The EA does not create the strategy. It does not guarantee profit. It does not fix a bad TradingView strategy, invalid signal logic, broker spread, slippage, closed market, insufficient margin or unsupported broker settings.

Runtime Conditions in MetaTrader 5

Before expecting the EA to execute orders, confirm these MT5 conditions:

• AlgoWayWS-MT5 EA is attached to a chart.
• MT5 Algo Trading is enabled.
• The EA is allowed to trade in its chart properties.
• DLL imports are enabled if required by the current WebSocket EA setup.
• The correct AlgoWay webhook UUID is entered in the EA inputs.
• The EA shows connected status in the MT5 Experts log or chart status.
• The broker symbol is visible in Market Watch and receiving quotes.

If MT5 returns Error 4752, the EA is probably blocked by algorithmic trading permissions. Read: How to fix MT5 Error 4752.

Connecting the EA to AlgoWay

The key connection value is shown in MT5 as Your Algoway Webhook here. It identifies which AlgoWay webhook route belongs to this MT5 terminal.

Name shown in MT5 Inputs	Meaning	Example
Your Algoway Webhook here	AlgoWay webhook UUID or the full https://algoway.co/<uuid> webhook URL. EA 2.20 extracts the UUID from the full URL automatically.	b7534616-6c8c-4582-8af4-7c143d323231
MAGIC_NUMBER	Magic number used by the EA to identify and manage only its own positions.	1973

If the EA is connected to the wrong webhook, valid alerts can reach AlgoWay but never reach the intended MT5 terminal. Do not attach two active EA instances to the same webhook: the single-instance guard keeps only one instance active.

Complete EA 2.20 Inputs Reference

The names below follow the labels shown in the MetaTrader 5 Inputs tab. This section explains only what a user needs to configure; internal MQL names and implementation details are intentionally omitted.

Connection and Execution

Symbols Mapping

TView Ticker N1 through TView Ticker N5 are the incoming ticker names. Broker Ticker N1 through Broker Ticker N5 are the exact MT5 symbols that should be used instead. Example: XAUUSD can be mapped to GOLD.pro. Leave unused pairs empty.

Position Size Mode

EA Based Trailing, Breakeven and Profit Lock

EA Based SL and TP

EA-Based Multiple Take Profit (EA 2.20)

Version 2.20 supports up to four internal Take Profit targets. This feature is optional: with Enable EA-managed multiple TP disabled, existing TP behavior is unchanged. All values below are set in the EA Inputs, not in webhook JSON.

Enabled TP distances must increase from one target to the next. In Percent close-size mode, total configured closing percentages must not exceed 100%. In Lots mode, each enabled stage must specify a positive lot amount that complies with the broker's volume step. The EA must remain running to monitor targets and execute these partial closes.

Martingale and Trade Limits

Sessions, Daily Window and Auto-Close

The informational rows SUMMER start 2nd Sunday of March and WINTER start 1st Sunday of November are reminders for the seasonal New York setting; they are not trading parameters.

Telegram Notifications and Diagnostics

Core TradingView to MT5 JSON Fields

A basic AlgoWay message for MetaTrader 5 contains four main fields:

Field	Example	Purpose
platform_name	metatrader5	Tells AlgoWay to route the command to MetaTrader 5.
ticker	EURUSD	Defines the trading symbol. It may need mapping to the broker symbol.
order_contracts	0.10	Defines the size value before final sizing mode and coefficient logic.
order_action	buy	Defines the action: buy, sell, flat, modify or mode-specific action.

When Override JSON order_contracts for new entries is enabled in the EA, the EA ignores the order_contracts value for BUY and SELL entry sizing and uses Fixed EA lot size instead. The field can still be present in the webhook message.

Basic market order:

{
  "platform_name": "metatrader5",
  "ticker": "EURUSD",
  "order_contracts": 0.10,
  "order_action": "buy"
}

TradingView Strategy Alert Example

For a TradingView strategy alert, use TradingView placeholders. TradingView replaces them when the alert fires.

{
  "platform_name": "metatrader5",
  "ticker": "{{ticker}}",
  "order_contracts": "{{strategy.order.contracts}}",
  "order_action": "{{strategy.market_position}}",
  "price": "{{close}}"
}

If this message reaches AlgoWay but MT5 does not trade, check the EA connection, symbol mapping, lot size, trade mode, broker session, margin and MT5 logs.

Supported Trade Actions

Action	Meaning	Typical use
buy	Open or process BUY-side command	Long entry
sell	Open or process SELL-side command	Short entry
long	Directional value treated as BUY where supported	TradingView strategy state mapping
short	Directional value treated as SELL where supported	TradingView strategy state mapping
flat	Close position logic	Exit signal or partial close workflow
modify	Modify an existing position	Update SL/TP by identifier

Trade Modes: Reverse, Hedge, Opposite and Inverse

The dropdown shown as Reverse / Hedge / Opposite / Inverse defines how the EA behaves when a new signal arrives while a position already exists on the same symbol.

Mode	Behavior	Best use case
Reverse	One-side model. The EA closes the opposite side and opens or keeps the new side according to signal logic.	Simple TradingView strategy automation where one side should be active.
Hedge	BUY and SELL can exist at the same time if the account supports it.	Hedging systems and independent long/short logic.
Opposite	The latest signal controls direction. The current position can be closed and the opposite side opened.	Strategies that flip immediately from long to short or short to long.
Inverse	Incoming direction is inverted before execution logic. BUY becomes SELL, SELL becomes BUY.	Counter-signal workflows or inverse strategy execution.

Detailed mode guide: How AlgoWay handles opposite trading signals.

Position size: Lots / Risk% / Balance%

The same order_contracts value can mean different things depending on the value selected in Position size: Lots / Risk% / Balance%.

EA-based fixed lot override

Override JSON order_contracts for new entries is a hard entry-size override. When enabled, BUY and SELL entries use Fixed EA lot size and the EA does not use the incoming order_contracts value to size that new entry.

This is useful for TradingView indicators or other signal sources where the signal determines direction while position size should remain fixed in MT5. The override applies to new entries only; flat commands continue to use Close size: Lots / Percent %.

Lots

order_contracts is treated as lots before coefficient and broker validation.

{
  "platform_name": "metatrader5",
  "order_action": "buy",
  "ticker": "EURUSD",
  "order_contracts": "0.10"
}

Risk%

order_contracts is treated as percent risk of equity. This mode requires a usable Stop Loss because the EA needs stop distance to calculate position size.

{
  "platform_name": "metatrader5",
  "order_action": "buy",
  "ticker": "EURUSD",
  "order_contracts": "1.0",
  "stop_loss": "100"
}

Balance%

order_contracts is treated as percent of balance. This is not the same as risk-by-stop-loss mode.

{
  "platform_name": "metatrader5",
  "order_action": "buy",
  "ticker": "EURUSD",
  "order_contracts": "5.0",
  "stop_loss": "100"
}

Coefficient for work with Lots

Coefficient for work with Lots multiplies lot sizing derived from order_contracts. When the EA-based fixed lot override is enabled for a new entry, the configured Fixed EA lot size is used instead of the JSON-derived entry size.

• 1 - keep the computed or provided size.
• 0.5 - use half the size.
• 2 - double the size.

Always test final lot size in a demo or small-volume environment before live trading. Wrong coefficient values can create invalid volume errors or oversized positions.

Order filling type: AUTO, FOK or IOC

• Auto Mode - lets the EA select a filling mode supported by the broker symbol.
• FOK - Fill or Kill. The requested volume must be filled completely or the order is rejected.
• IOC - Immediate or Cancel. The broker may fill the available part and cancel the remainder.

Use Auto Mode unless the broker or prop firm explicitly requires another mode. MT5 retcode 10030 means the selected filling mode is not supported for that symbol.

Pending orders: Legacy / Reject / Chase

This setting controls how the EA handles a LIMIT or STOP order when the requested entry price is no longer valid for that pending-order type at the moment MT5 receives the command.

• Legacy - keeps compatibility with older setups and can switch between LIMIT and STOP when the requested price is on the wrong side of the market.
• Reject - keeps the requested pending-order type and rejects the order when the requested price is invalid for that type.
• Chase - keeps the requested pending-order type and adjusts the entry toward the nearest valid broker price instead of changing LIMIT to STOP or STOP to LIMIT.

Use Legacy for existing configurations that already rely on automatic conversion. Use Reject when the strategy must preserve the exact requested type and should fail instead of changing the order. Use Chase when preserving the requested type is important but a small price adjustment is acceptable.

Symbol Mapping: TradingView Ticker vs MT5 Broker Symbol

TradingView and MT5 brokers often use different symbol names. Enter the TradingView value in TView Ticker N1 and the exact MT5 symbol in Broker Ticker N1. The same rule applies to pairs N2 through N5.

TradingView ticker	MT5 broker symbol
DE40	GER40
XAUUSD	GOLD
US30	DJ30
EURUSD	EURUSD.a

If the symbol is not found, the trade will not open. Always confirm the exact broker symbol in MT5 Market Watch.

SL/TP Model A: Levels from JSON

Model A means the alert message itself sends Stop Loss, Take Profit or trailing fields.

Exact SL/TP Prices

{
  "platform_name": "metatrader5",
  "order_action": "sell",
  "ticker": "XAUUSD",
  "order_contracts": "0.05",
  "sl_price": "2055.50",
  "tp_price": "2038.00"
}

Distance-Based SL/TP

{
  "platform_name": "metatrader5",
  "order_action": "buy",
  "ticker": "BTCUSDT.P",
  "order_contracts": "0.10",
  "stop_loss": "150",
  "take_profit": "300"
}

Priority rule: if sl_price or tp_price are set and non-zero, price levels should take priority. Otherwise distance fields such as stop_loss and take_profit are used.

SL/TP Model B: Levels from EA Inputs

Model B means the EA applies internal SL/TP values from the Inputs tab.

• Use fixed SL/TP (pips) inside EA - enables fixed EA distances for new entries.
• Internal SL distance in pips - fixed Stop Loss distance.
• Internal TP distance in pips - fixed Take Profit distance.
• Do not place SL in MT5 - suppresses Stop Loss placement.
• Do not place TP in MT5 - suppresses Take Profit placement.

When Use fixed SL/TP (pips) inside EA is enabled, the EA uses the internal distances for that entry instead of the alert-provided distance values. Exact behavior still depends on the selected PIP type and broker stop restrictions.

PIP type: AUTO/TRADINGVIEW/PERCENT/POINTS/STANDARD

This setting defines how every distance expressed through Stop Loss, Take Profit, trailing, breakeven or profit-lock values is converted into an MT5 price distance.

• AUTO - follows the broker symbol’s digits and point format.
• TRADINGVIEW - keeps the existing AlgoWay TradingView-compatible behavior: Forex symbols use ten broker points per pip, while other broker calculation types use one broker point per pip.
• PERCENT - treats distance values as percentages of the relevant price instead of pips or points.
• POINTS - treats each distance unit as exactly one broker point.
• STANDARD - treats one pip as ten broker points for every symbol. This is useful when different brokers classify the same market differently, for example when gold is exposed as XAUUSD, GOLD or a broker-specific symbol suffix.

Existing users can keep their current mode. STANDARD is an additional option and does not change the behavior of AUTO, TRADINGVIEW, PERCENT or POINTS.

SL/TP Reference: Bid/Ask or Entry Price

The setting shown as SL/TP reference: Bid/Ask or Entry Price controls which price is used as the reference for distance-based Stop Loss and Take Profit calculations.

• Bid/Ask - preserves the quote-side calculation used by the EA. For distance-based SL/TP, the reference depends on trade direction and whether the level is a Stop Loss or Take Profit.
• Entry Price - bases distance-based SL/TP on the position entry price. For market orders, the EA first opens the trade, resolves the actual MT5 position and actual fill price, then recalculates the applicable distance-based SL/TP and applies the corrected levels to that position.

Absolute sl_price and tp_price values are not converted into distances by this selector. When explicit price levels are supplied, those levels keep priority over stop_loss and take_profit distance fields.

For pending orders, Entry Price mode can use the requested pending-order price as the reference before the order is sent. For market orders, the actual executed entry price is used after the position is opened and identified.

Trailing Stop from JSON and EA Inputs

Trailing can be enabled per trade with trailing_pips.

{
  "platform_name": "metatrader5",
  "order_action": "buy",
  "ticker": "GBPUSD",
  "order_contracts": "0.10",
  "stop_loss": "120",
  "trailing_pips": "80"
}

If trailing_pips is present, trailing is enabled for that trade. If it is absent, the EA uses Enable Trailing SL, Trailing Step in pips and Start trailing after N pips, 0 = immediate.

Delayed Trailing Activation with trail_points

trail_points allows trailing stop to start only after the trade moves a specified number of pips into profit.

• trail_points = 0 - trailing starts immediately after the position opens.
• trail_points = 50 - trailing starts only after 50 pips of profit.

{
  "platform_name": "metatrader5",
  "ticker": "SP500",
  "order_action": "buy",
  "order_contracts": "4",
  "trailing_pips": "20",
  "trail_points": "50"
}

In this example, the trailing step is 20 pips, but trailing starts only after the trade moves 50 pips in profit.

Breakeven

Breakeven logic moves Stop Loss to the entry area after the trade reaches a configured profit distance.

• Enable Breakeven - enables breakeven logic.
• Move SL to BE after X pips profit - defines when breakeven activates.

Breakeven is useful when a strategy should remove open risk after the market moves in the intended direction.

Profit Lock

Profit Lock is more advanced than basic breakeven. It can move Stop Loss so that a defined amount of profit is protected after the trade reaches a trigger.

• Enable Profit Lock factor - enables profit lock logic.
• Delta trigger - profit threshold that activates the feature.
• Profit Lock after XX pips - profit distance the EA tries to protect after activation.

In simple terms: first the trade reaches the trigger, then the EA moves SL to protect the configured profit.

Partial Close with Close Size Mode

The setting shown as Close size: Lots / Percent % controls whether the EA closes positions by lots or by percentage of the initial position volume.

• Lots - order_contracts in a flat signal is treated as lots.
• Percent % - order_contracts in a flat signal is treated as percent of the initial position.

{
  "platform_name": "metatrader5",
  "ticker": "SP500",
  "order_action": "flat",
  "order_contracts": "25"
}

If the initial position was 4.00 lots and Close size: Lots / Percent % is set to Percent %, this command closes 25% of the initial position, which is 1.00 lot.

close_side for Hedge Workflows

close_side is used with flat to close only one side where supported.

{
  "platform_name": "metatrader5",
  "order_action": "flat",
  "ticker": "EURUSD",
  "close_side": "long"
}

• long or buy - close BUY-side positions.
• short or sell - close SELL-side positions.

If close_side is used with buy, sell or modify, treat it as invalid. It belongs to close/flat logic.

Modify Existing Positions

modify is used to update an existing position instead of opening a new one. The position must be identified by comment or tv_order_id depending on your route.

{
  "platform_name": "metatrader5",
  "order_action": "modify",
  "ticker": "ETHUSDT",
  "comment": "TV#12345",
  "stop_loss": "140",
  "take_profit": "280"
}

If no matching position is found, the modification cannot be applied.

Martingale

Enable increasing the lot after a losing trade activates martingale sizing. Lot increase coefficient defines the multiplier for the next step. This is a high-risk feature and should be tested carefully before live use.

Do not enable martingale just because it exists. Use it only if the trading system was designed and tested for this risk model.

Trade Limits, Sessions, Daily Window and Auto-Close

Trade Limits

• Max daily loss in % - closes all EA positions and blocks new trading for the rest of the calculated trading day after the threshold is reached. Zero disables it.
• Max drawdown per trade in % - closes an individual EA position when adverse price movement from its open price reaches the configured percentage. This is a price-drawdown calculation, not account-equity risk. Zero disables it.
• Max positions, if 0 = no limit - limits all open positions belonging to the EA magic number.
• Max positions per direction, if 0 = no limit - separately limits BUY and SELL positions.
• Max spread in points, 0 = disabled - blocks new entries when the current Ask-Bid spread exceeds the selected broker-point value. Closing actions remain available.
• Max price deviation in points, 0 = AUTO - sets the allowed market-order price deviation in broker points. Zero lets the EA select an adaptive value automatically.

Fixed UTC Sessions

The three session switches are always evaluated in UTC:

• London (07:00-16:00)
• New York (12:00-22:00)
• Tokyo (22:00-07:00)

At least one selected session must be active when an entry command arrives. The enabled sessions are combined: an entry is allowed when the current UTC time is inside any enabled session and also inside the Daily Trade Window.

NY session: Winter or Summer

NY session: Winter or Summer controls the trading-day reset used by daily-loss calculations and Auto-Close:

• WINTER - reset at 22:00 UTC.
• SUMMER - reset at 21:00 UTC.

This setting does not move the fixed New York (12:00-22:00) session row.

Daily Window Time Mode and Daily Trade Window

Daily Window Time Mode selects which clock is used to evaluate Daily Trade Window:

• UTC - coordinated universal time. This is the default and preserves older EA behavior and existing setup files.
• Broker Time - MT5 trading-server time, the same time basis used in broker trade history.
• Local Time - the Windows clock of the computer or VPS running MT5.

Daily Trade Window uses HH:MM-HH:MM. Example: 01:30-23:30. A range that crosses midnight is valid, for example 23:30-21:30.

For verification, the MT5 Experts log writes the current UTC, Broker and Local timestamps together with the selected window mode in the [SCHEDULE] record. When using Local Time, make sure the Windows/VPS clock and time zone are correct.

Auto-Close and entry delay

Auto close: None / End of Day / End of Week controls automatic position closing near the calculated end of the trading day or week. Close positions before market end, minutes defines how early the closing process begins.

Allow new trades after market open, minutes blocks new entries for the selected number of minutes after the calculated market or trading-week open. Zero disables the delay.

If a signal is rejected by a session, Daily Trade Window, spread, entry delay or position limit, the webhook is not necessarily broken. The EA followed the configured Inputs.

Telegram Notifications and Trade Reports from the EA

The EA can use a Telegram bot for two separate purposes: connection notifications and trade reports. These EA-side features are also independent from AlgoWay Telegram notifications configured in the dashboard.

• Telegram notify for AlgoWay disconnect - notifies the selected chat when the EA loses its AlgoWay connection and when the connection is restored.
• Telegram reports for positions and pending orders - reports actual MT5 position and pending-order activity, including trading operations observed by the EA.
• Telegram chat id - destination chat for the messages.
• Telegram bot token - bot token used to send the messages.

Dashboard Telegram notifications and EA Trade Reports serve different purposes: dashboard notifications report incoming alerts received by AlgoWay, while EA Trade Reports report the resulting trading operations in MetaTrader 5. Enabling or disabling one does not enable or disable the other.

Add https://api.telegram.org in MT5 under Tools >> Options >> Expert Advisors >> Allow WebRequest for listed URL before enabling these EA features.

Debug logging: 0 = disabled, 1 = enabled is separate from Telegram. Set it to 1 only when detailed MT5 diagnostics are needed; normal users can leave it at 0.

EA-side Telegram reporting is not the same as using Telegram as a signal source. For Telegram signal copying, use: AI Telegram signal copier in AlgoWay.

Wrapped Values

Some alerts may send wrapped values such as:

{
  "platform_name": "metatrader5",
  "order_action": "buy",
  "ticker": "EURUSD",
  "order_contracts": "0.10",
  "stop_loss": "stop_loss=100",
  "take_profit": "take_profit=200",
  "trailing_pips": "trailing_pips=80"
}

Wrapped values should be used only when the current route explicitly supports them. Clean numeric JSON values are easier to debug.

Common Problems and Where to Fix Them

Problem	Likely layer	Guide
AlgoWay does not receive the alert	TradingView webhook / JSON	Webhook Error 415 guide
EA does not receive commands	Webhook UUID / EA connection	MT5 setup guide
MT5 says trading disabled	Algo Trading permission	Error 4752 guide
Order is rejected	Broker execution / request parameters	Error 4756 guide
Wrong symbol	Symbol mapping	Common MT5 errors guide
SL/TP rejected	Stop level, freeze level, points/pips	Risk management guide
SL/TP distance is correct but the resulting level is shifted by the spread	SL/TP reference mode	Compare Bid/Ask with Entry Price in the EA Inputs
Trade opens outside the expected daily time	Daily Window Time Mode does not match the clock used by the user	Check UTC, Broker Time or Local Time, then verify Daily Trade Window
Entry rejected while the market is open	Max spread, session, daily window or position limit	Check the MT5 Experts log for [SPREAD], [SCHEDULE] or [LIMIT]

Safe Testing Procedure

When setting up a new MT5 automation route, test in layers:

1. Confirm that the EA is connected in MT5.
2. Confirm Reverse / Hedge / Opposite / Inverse, Position size: Lots / Risk% / Balance%, and Pending orders: Legacy / Reject / Chase.
3. Keep Daily Window Time Mode on UTC for an existing configuration, or deliberately select Broker Time or Local Time for a new one.
4. Temporarily use Daily Trade Window 00:00-23:59 and ensure at least one UTC session is enabled.
5. Send a simple market order with a very small valid lot.
6. Check AlgoWay Webhook Logs and MT5 Experts/Journal logs.
7. Test Max spread in points, 0 = disabled with a safe value before enforcing it live.
8. Add exact SL/TP prices, then test distance-based SL/TP with the intended PIP type: AUTO/TRADINGVIEW/PERCENT/POINTS/STANDARD.
9. If you use distance-based SL/TP, compare Bid/Ask and Entry Price reference modes and confirm the resulting levels in MT5.
10. Add trailing stop, breakeven or profit lock one feature at a time.
11. Test close/flat logic and partial close only after full close works correctly.

How to Use This v206 Reference

The URL contains v206 because it was created during an earlier documentation cycle. The content has since been updated to match the current AlgoWayWS-MT5 EA 2.20 workflow while preserving the existing address for users who may still have older links or references.

This reference now covers the main topics required for the current MT5 automation workflow:

• TradingView to MT5 EA;
• MT5 webhook EA;
• TradingView alerts to MetaTrader 5;
• MT5 Expert Advisor JSON fields;
• MT5 EA trailing stop automation;
• MetaTrader 5 WebSocket EA;
• AlgoWayWS-MT5 EA guide.

Related AlgoWay Guides

• How to connect TradingView to MetaTrader 5 with AlgoWay EA
• How to install an MT5 Expert Advisor for AlgoWay automation
• AlgoWay JSON schema guide
• Advanced risk management and trade automation
• How AlgoWay handles opposite trading signals
• MetaTrader 5 common errors in AlgoWay
• How to fix MT5 Error 4752
• How to fix MT5 Error 4756
• How to fix AlgoWay webhook Error 415
• AI Telegram signal copier in AlgoWay

Final Summary

AlgoWayWS-MT5 EA 2.20 is the current MT5 execution component for AlgoWay automation. It adds four configurable EA-managed Take Profit stages with pips/percent distances and percent/lots partial-close sizing. It supports Reverse, Hedge, Opposite and Inverse execution, lot/risk/balance sizing, an EA-based fixed lot override for new entries, configurable pending-order handling, broker-compatible filling, five distance modes including STANDARD, Bid/Ask or Entry Price SL/TP reference, fixed or signal-driven SL/TP, trailing, breakeven, profit lock, partial close, symbol mapping, spread and price-deviation controls, position limits, UTC sessions, selectable Daily Trade Window clocks, End-of-Day or End-of-Week Auto-Close, delayed entries after market open, independent Telegram connection notifications and EA Trade Reports, stronger confirmation for closes and SL/TP modifications, and optional debug diagnostics.

If you want to automate TradingView alerts to MetaTrader 5, start with a clean AlgoWay webhook, install the current EA, confirm the WebSocket connection, send valid JSON, test a small market order, and only then enable advanced risk and management features.
